NEW Entry-Level Portable Sawmill for Hobbyists

Entry-level portable sawmill you can count on featuring a strong twin rail LX frame, quick up/down saw head, and quick-set log handling.

Benefits
  • Easy Shipping and Assembly
  • Built in the USA
Description LX55 Portable Sawmill

Start sawing logs into timber with the robust, entry-level LX55 portable sawmill! Designed for entry-level sawyers, hobbyists, and woodworkers, the LX55 portable sawmill replaces Wood-Mizer’s current entry-level LT10 sawmill while providing a larger cut capacity, more power options, and many upgraded features. The LX55 features the rigid LX Frame sawhead tower that holds the control panel, engine, and sawmill head in a rigid, stable structure that travels on twin parallel steel bed rails. The simple and sturdy sawmill design enables the LX55 to make accurate, precise cuts quickly and efficiently.

Operation

Loaded and turned manually with a cant hook or log peavey, logs are secured onto the low profile bed by two adjustable side supports and two adjustable log clamps that tightly fasten the log and allow for cuts within 25mm of the bed. To prepare for cutting, saw head height is positioned by a quick turn of the up/down hand crank. Once the blade is effortlessly engaged with a handle, cutting is accomplished by steadily pushing the saw head along the length of the log by using a no-maintenance push feed bar. Turned on and off with a manual valve, a water tank feeds lubrication directly to the blade to improve cutting performance and keep the blade clean. The optional adjustable blade guide arm keeps the blade well supported while cutting various sized material. Once the cut is completed, the head is raised up, pulled back, and lowered into position for the next cut.

Features

  • 66cm max log diameter with 56cm max width of cut
  • 3.8m length of cut or unlimited with 1.5m bed extensions
  • Rigid LX Frame sawhead tower with heavy-duty twin rail bed construction
  • Easy shipping and assembly
  • Built in the USA

Popular Options

  • 1.5m bed extensions can be added to saw longer lengths (no practical limit)
  • Adjustable blade guide arm supports the blade while sawing various sized material
  • 12 adjustable bed leveling feet for simple leveling of the bed



The LX55 portable sawmill ships on a single pallet, comes with one Wood-Mizer sawmill blade, and requires minimal assembly time so you can start sawing within a few hours of receiving your sawmill.

Read More
Specifications LX55 Portable Sawmill
Specifications
Power
Power Selections 5.2kW electric
14HP petrol
7kW petrol
Cutting Capacity
Max Width of Cut 56cm (22")
Max Log Diameter 66cm (26")
Max Depth of Cut 26cm (10 1/2")
Max Log Length 3.78m (12' 5")
Max Log Length (with extensions) Unlimited
Blade
Blade Length 3.35m (132")
Blade Lubrication System 18 L (5 Gal.) Water Tank with On/Off Valve
Blade Thickness 1mm (.042'')
Blade Width 32mm (1 1/4'')
Blade Guides Size 31.75mm (1 1/4")
Blade Wheels
Blade Wheel Type Belted Blade Wheels
Head Features and Options
Operator Location Walk Along Push Feed
Setworks N/A
Head Forward/Reverse Push Feed
Head Up/Down Hand Crank
Blade Engagement Manual Lever
Debarker N/A
Board Removal N/A
Bed Features and Options
Side Supports 2 Side Supports
Log Leveling N/A
Log Turning Manual
Log Loading Manual
Trailer Package N/A
Log Clamping 2 Adjustable Log Clamps
Additional Bed Options Optional 1.5m Bed Extension
Machine Dimensions and Requirements
Bed Construction Twin Rail
Frame Construction xFRAME
Mobility Stationary
Delivery Methods Pallet
